General
Unloading system | Rotating |
Load capacity | 7700 lb |
Chassis | Articulated |
Water skip capacity | 1.33 cu yd |
Level skip capacity | 2.34 cu yd |
Heaped skip capacity | 2.78 cu yd |
Empty weight | 6241 lb |
Transmission | Hydrostatic |
Reversibility | Non-reversible |
Engine
Brand | Kubota |
Model | D1803-CR-T-E5B |
Power | 44 hp |
Torque | 150,5@1500 |
No. of cylinders | 3 |
Emissions | Stage V - EPA Tier 4f |
Noise level (LwA) | 101 dB(A) |
Driving
Max. speed | 12 mph |
Maximum gradient | 54 % |
External turning radius | 178 in |
Traction | 4x4 |
Tyres | 11.5/80-15,3 |
Hydraulic system
Hydraulic circuit | 0.73 cu in gear pumps |
Flow rate | 8.2 gal/min |
Working pressure | 2465 psi |
Tank capacity
Fuel | 11.6 gal |
Hydraulic system | 10.6 gal |
Brakes
Service | Hydraulic, sealed, multi-disc |
Parking | Negative |
