Degelman Pro Till 25

What Makes the Pro-Till 25 a Game Changer?

• Tri-Fold Frame = Triple the Advantage

  • Three evenly sized sections allow unmatched ground contouring

  • Matches the working depth of the larger Pro-Till 30 and 36 models

• Low Pressure, High Performance

  • Equipped with VF 389 tires

  • Operates at 30% lower inflation than traditional flotation tires

  • Reduces soil compaction and preserves field integrity

• High Performance Features

  • True Greaseless Technology

    • Exclusive self-lubricated, zero-maintenance bushings

    • Friction liner on a glass fiber structure for long-lasting performance

    • 2.5" oversized electroless nickel-plated pins — largest in the market by 60%

  • Built Tougher Where It Counts

    • Optional HD arms for 24” discs

    • Designed for aggressive tillage and deeper ground penetration

• Superior Tri-Fold Transportability

  • Folds to just 14' 11" wide and 12' tall in transport mode

• Horsepower Requirements

  • 12–15 HP per foot at 2" or less depth for 8–12 mph operation with 20" blades

  • 15–20 HP per foot at 2" or more depth for 8–12 mph operation with 20" blades

  • (Horsepower needs may vary based on soil type)




General Dimensions

• Transport Height (Rubber Roller, Low/High): 12'8" / 13'

• Transport Height (Cage Roller, Low/High): 12' / 12'6"

• Transport Width (High/Low Position): 13'9" / 14'11"

• Transport Length: 20'11"

• Field Length: 26'4"

• Wheelbase: 11'4"

Weight

• Total Weight (with rubber roller, scraper & 20" discs): 25,500 lbs

• Hitch Weight: 6,000 lbs

Disc Configuration

• Number of Discs (Center): 20

• Number of Discs (Per Wing): 19

• Disc Spacing: 5" overall (10" per row)

• Disc Arm Mounting: Rubber torsion with 4 elements per arm

Roller Specs

• Roller Size (Center & Wing): 8'2" each

Tires

• Tire Size (Center): 560/50R22.5 VF

• Tire Size (Wing): 500/45R22.5 VF

Cylinders

• Transport Cylinder: 5" x 40" x 2"

• Wing Cylinder: 4" x 28" x 2"

• Wheel Depth (Master/Slave): 4.25" x 8" x 2" / 3.75" x 8" x 2"

• Roller Depth (Master/Slave): 4.25" x 8" x 2" / 3.75" x 8" x 2"

• Hydraulic Jack Cylinder: 4" x 12" x 2"

Performance & Features

• Working Depth: Up to 8" with 20" discs, 9" with 22" discs

• Hydraulic Jack: Standard

• Safety Lights: Standard

• Soil Deflector: Standard

Horsepower Requirements (Pro-Till 25)

• At 2” or less working depth (with 20” blades):
  ? Requires 12 to 15 HP per foot
  ? Achieves 8–12 mph depending on soil type

• At 2” or more working depth (with 20” blades):
  ? Requires 15 to 20 HP per foot
  ? Achieves 8–12 mph depending on soil type

Horsepower Range by HP/Foot:

• 12 HP/ft: ~300 HP

• 15 HP/ft: ~375 HP

• 20 HP/ft: ~500 HP
