Terra King TKV21

Yard material collection can now be effortless with the introduction of the TKV 21, a PTO-driven system designed to meet the needs of compact utility tractors. Whether it's handling grass in the spring or leaves in the fall, the TKV 21 is the ultimate material collection system that will revolutionize your approach to yard maintenance.
Get a Quote
Ask a Question

Series Models

TKV21

TKV21 Collection System, Includes Universal Wiring Kit, & Caster Wheels. Boot Kits Ordered Separately.

Series Models

TKV21

TKV21 Collection System, Includes Universal Wiring Kit, & Caster Wheels. Boot Kits Ordered Separately.

Terra King TKV21

Material Collection System

The Terra King TKV21 Material Collection System is a PTO-driven bagger built for compact and sub-compact tractors that need serious grass and leaf collection capacity without sacrificing mower deck performance. With its large hopper, powerful blower, and dump-from-seat unloading, the TKV21 gives operators a cleaner, faster way to handle seasonal cleanup and regular mowing collection.

Hopper Capacity

20 Bushels

Airflow Speed

100+ MPH

Dump System

From the Seat

Key Features

  • Dump-from-seat unloading uses a rocker switch and electric actuator for easier operation
  • 20-bushel hopper provides high-capacity collection for longer mowing sessions
  • PTO-powered blower uses a poly urethane 5-blade impeller with airflow speeds over 100 MPH
  • Blower mounts on the TKV instead of the mower deck to help preserve mower cut quality and deck balance
  • Integrated steel storage stands help simplify attachment, removal, and storage

Specifications

  • Hopper Capacity: 20 bu. / 25 cu. ft.
  • Weight: 520 lbs empty / 650 lbs full, depending on material
  • Ground Clearance: 6-3/8"
  • Fan Diameter: 15"
  • Fan Speed: 3,000 RPM
  • Hose Size: 8" diameter x 5' length
  • PTO Requirement: 540 RPM rear shaft with 17 PTO HP minimum
  • 3-Point Hitch: Category 1 with 650+ lb lift capacity
  • Electrical: 12V / 30A connection

Requirements & Compatibility

Tractor Requirements

Engine HP: 20 minimum

PTO HP: 17 minimum

Mower Deck: Mid-mount side-discharge deck

Boot Kit: Mower deck boot kit sold separately

Front Weight: Minimum 200 lbs required

Compatible Tractor Families

Kubota BX2380 and BX2680

Kubota B01 Series with 60" decks

Kubota LX Series with 60" decks

John Deere 1023E, 1025R, and 2025R

John Deere 2032R and 2038R

John Deere 3 Series compact tractors

Why Customers Choose the TKV21

For customers who need more capacity and less hassle during mowing season or fall cleanup, the Terra King TKV21 offers a serious collection solution with PTO-powered performance, electric dump convenience, and compact tractor compatibility. It is a strong fit for operators who want cleaner results, fewer stops, and a more efficient way to collect grass and leaves.

Resources

TerraKing Hopper Style Grass Catcher
TerraKing Hopper Style Grass Catcher
Wednesday, April 22, 2020

We're going to walk around this attachment here to show you some of its features, maybe you're going to find that this is a way that you can really improve your fall leaf collection chores. The TerraKing TKV is actually made locally to us here, right down here in Lancaster, Pennsylvania.
