Woods DB4.20
The Woods DB4.20 is a 48" standard rotary tiller built for compact and subcompact tractors with 15-25 PTO HP. It features a durable gear-driven side drive, 540 RPM PTO, slip clutch protection, forward-rotating C-tines, adjustable skid shoes, Quick-Hitch readiness, and a 6-year gearbox warranty. Designed for gardens, food plots, landscaping, and small field preparation, it helps break soil and create a fine seedbed with fewer passes.
Get a Quote
Ask a Question
Series Models
DB4.20
The Woods DB4.20 is a 48" gear-driven rotary tiller for 15-25 PTO HP tractors, built to prepare gardens, food plots, and small fields with a fine seedbed finish.
Series Models
DB4.20
The Woods DB4.20 is a 48" gear-driven rotary tiller for 15-25 PTO HP tractors, built to prepare gardens, food plots, and small fields with a fine seedbed finish.
Woods DirtBreaker Tillage
Woods DB4.20 Rotary Tiller
The Woods DB4.20 is a 48" standard-duty rotary tiller built for compact and subcompact tractors that need dependable soil preparation in gardens, food plots, landscaping areas, and small fields. With a durable gear-driven side drive, forward tine rotation, adjustable skid shoes, and Quick-Hitch-ready connection, it helps create a finely tilled seedbed with fewer passes.
Built For Seedbed Prep
- 48" working width
- Recommended for 15-25 PTO HP tractors
- 540 RPM PTO with slip clutch protection
- Gear-driven side drive for durability
- Maximum tilling depth up to 6.9"
Product Features
A compact rotary tiller designed to break ground, refine soil, and prepare planting areas with reliable gear-drive performance.
48" Working Width
- Ideal size for compact and subcompact tractors
- Fits gardens, food plots, and small acreage work
- Overall width of 53.1" for practical coverage
Gear-Driven Side Drive
- More durable than chain-driven tillers
- Designed for long-term reliability
- Requires less maintenance in tough conditions
Forward Rotation Tines
- 244 RPM rotor speed
- 36 C-shaped tines across 6 blade flanges
- Helps create a fine, finished seedbed
Adjustable Depth Control
- Maximum tilling depth up to 6.9"
- Adjustable skid shoes for controlled working depth
- Six skid shoe depth settings from 0.4" to 2.2"
Quick-Hitch Ready
- Cat. 1 tractor hitch compatibility
- Quick-Hitch-ready with bushings included
- Parking stand included for easier connection
Gearbox Protection
- Heavy-duty cast iron gearbox housing
- Slip clutch driveline protection
- 6-year gearbox warranty including parts, labor, and seals
Improvements For Soil Prep
- Better seedbed quality: forward-rotating C-tines break and refine soil for planting in fewer passes.
- Improved durability: the gear-driven side drive is built for tougher conditions and reduced maintenance.
- More controlled tillage: adjustable skid shoes help match working depth to soil conditions and crop needs.
- Easier hookup: Quick-Hitch-ready design and parking stand make tractor connection more convenient.
- Cleaner finish: the tapered tailgate helps remove furrows and leave a smoother final seedbed.
Key Specs
- Model: Woods DB4.20
- Type: Standard rotary tiller
- Working width: 48"
- Tractor PTO HP: 15-25
- PTO speed: 540 RPM
- Rotor speed: 244 RPM
- Number of tines: 36
- Approximate weight: 570 lbs.
Application & Use In The Field
A practical soil-preparation tool for gardeners, landowners, hobby farms, landscapers, and small acreage operators.
Garden Preparation
- Break compacted garden soil before planting
- Prepare vegetable beds, flower beds, and cover crop areas
- Mix organic matter into the topsoil layer
Food Plots
- Create seedbeds for wildlife plots
- Work small acreage fields with compact tractors
- Help improve seed-to-soil contact before planting
Landscape Work
- Prepare lawns, beds, and small jobsite areas
- Refine soil after grading or material placement
- Create a smoother surface before seeding or sod work
Small Field Maintenance
- Refresh compacted soil in small plots or utility areas
- Support seasonal planting and renovation work
- Pair with compact tractors for repeatable property tasks
Compact Tillage With Durable Gear-Drive Performance
The Woods DB4.20 gives compact tractor owners a strong, easy-to-connect rotary tiller for breaking soil, refining seedbeds, and preparing gardens, plots, and small fields for productive planting.
