New Equipment   >   Hay Tools   >   Disc Mowers
Kubota

Kubota DM1000 Series

The Kubota DM100 Series Disc Mowers offer a blend of effectiveness and dependability, instilling the confidence you seek in a hay tool. With the convenience of a hydraulic cylinder, you can effortlessly elevate the disc mower without relying on the three-point linkage. Moreover, when transporting it to and from the field, the mower efficiently folds into a vertical position. The inclusion of a spring-loaded breakaway system further minimizes damage caused by obstacles, safeguarding the cutterbar.

Get a Quote
Financing Available
Nationwide Shipping
Ask a Question

Series Models

DM1017

5' 6" Cutting Width, Cat II 3-Point, 540 PTO, 4 Discs with 3 Blades Each, -45 / +45 Degree Op Range, Min. 36 PTO HP, 860 lbs.
DM1022

7' 2" Cutting Width, Cat II 3-Point, 540 PTO, 6 Discs with 3 Blades Each, -45 / +45 Degree Op Range, Min. 42 PTO HP, 948 lbs.
Item In-Stock Item is In-Stock!
DM1024

7' 9" Cutting Width, Cat II 3-Point, 540 PTO, 6 Discs with 3 Blades Each, -45 / +45 Degree Op Range, Min. 46 PTO HP, 992 lbs.

Series Models

DM1017

5' 6" Cutting Width, Cat II 3-Point, 540 PTO, 4 Discs with 3 Blades Each, -45 / +45 Degree Op Range, Min. 36 PTO HP, 860 lbs.
DM1022

7' 2" Cutting Width, Cat II 3-Point, 540 PTO, 6 Discs with 3 Blades Each, -45 / +45 Degree Op Range, Min. 42 PTO HP, 948 lbs.
Item In-Stock Item is In-Stock!
DM1024

7' 9" Cutting Width, Cat II 3-Point, 540 PTO, 6 Discs with 3 Blades Each, -45 / +45 Degree Op Range, Min. 46 PTO HP, 992 lbs.

Available Working Widths:

  • DM1017 – 5’6”
  • DM1022 – 7’2”
  • DM1024 – 7’9”

Spring-Loaded Breakaway:

In the presence of an obstacle, the DM1000 series responds by swinging backward to shield the cutterbar. By reversing, the mower is effortlessly reset to its operational position.

Efficient Lift on Headlands:

Raising the mower is a simple task accomplished via a hydraulic cylinder, all without engaging the tractor's 3-point linkage. This approach reduces wear on both the tractor and the machinery, as it keeps the PTO in a consistent position, minimizing transmission vibrations.

Vertical Transport Position:

During transport, the mowers neatly fold into a vertical position situated well behind the tractor. This configuration ensures excellent weight distribution and transport stability, with the center of gravity in close proximity to the tractor.

Counter-Rotating Three-Bladed Discs:

Kubota mowers feature three blades per disc, maintaining a continuous cutting process. This results in a one-third reduction in the load per blade, uniform load distribution on the drive, smoother power utilization, and the production of an even, neatly cut stubble.
